MikroTik hAP ax3 Wireless Access Point - C53UiG+5HPaxD2HPaxD

Description

hAP ax3 is our most powerful AX device with the best wireless network coverage so far. It features a modern quad-core ARM CPU running at 1.8 GHz and enough memory (1GB RAM + 128 MB NAND) for most tasks. Complex firewall rules, IPsec hardware encryption, Wireguard, BGP, advanced routing, or multiple remote work VPN tunnels won’t stop your family from comfortable browsing, streaming, gaming, and so on. There’s enough processing power for everyone. And we’ve added a speedy USB 3 port for all your storage purposes or an additional LTE modem.

Depending on your overall setup, our AX product family offers up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum! Potent external antennas (via built-in RP-SMA female ports) allow reaching gain up to 5.5 dBi, so you can forget about Wi-Fi Boosters and other tricks. Smooth and fast connectivity for your whole apartment – that’s just how hAP ax3 works.

Specifications

• Product code - C53UiG+5HPaxD2HPaxD

• Architecture - ARM 64bit

• CPU - IPQ-6010

• CPU core count - 4

• CPU nominal frequency - auto (864 - 1800) MHz

• CPU Threads count - 4

• Switch chip model - IPQ-6010

• RouterOS license - 6

• Operating System - RouterOS v7

• Size of RAM - 1 GB

• Storage size - 128 MB

• Storage type - NAND

• MTBF - Approximately 200'000 hours at 25C

• Tested ambient temperature - -40°C to 70°C

Ethernet

• 10/100/1000 Ethernet ports - 4

• Number of 1G Ethernet ports with PoE-out - 1

• Number of 2.5G Ethernet ports - 1

Peripherals

• Number of USB ports - 1

• USB Power Reset - Yes

• USB slot type - USB 3.0 type A

• Max USB current (A) - 1.5

Powering

• Number of DC inputs - 2 (DC jack, PoE-IN)

• DC jack input Voltage - 12-28 V

• Max power consumption - 38 W

• Max power consumption without attachments - 15 W

• PoE in - Passive PoE

• Cooling type - Passive

• PoE in input Voltage - 18-28 V

PoE-out

• PoE-out ports - Ether 1

• PoE out - Passive PoE

• Low voltage PoE-Out current limit - 0.625 A

• Max total out (A) - 0.625 A

• Total output current - 0.625

• Total output power - 15

Certification & Approvals

• Certification - CE, FCC, IC, EAC, ROHS

• IP - 20

Other

• CPU temperature monitor - Yes

• Mode button - Yes

Package Contents

• 1 x Router

• 1 x Power Adapter

• HGO Indoor Antenna KIT

Warranty

• 1 Years Warranty

Manufacturer Info

• Manufactured By: Mikrotikls SIA, Unijas iela 2, Riga, Latvia.

• Imported By: VT, New Delhi, INDIA.

• Country Of Origin: Vietnam
