MikroTik hEX PoE 5 Port Gigabit Ethernet Router RB-960PGS

Description

hEX PoE 5x Gigabit Ethernet with PoE output for four ports, SFP, USB, 800MHz CPU, 128MB RAM, RouterOS L4

hEX PoE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and a SFP port for adding optical fiber connectivity. The ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit.

It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports. Less power adapters and cables to worry about! Max current is 1A per port, Ethernet ports are shielded.

It also supports passive PoE input and passive or 802.3af/at PoE output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power at/af mode B (4,5+)(7,8-) compatible devices, if 48-57 input voltage is used.

Specifications

• Product code - RB960PGS

• CPU - QCA9557

• CPU nominal frequency - 800 MHz

• CPU core count - 1

• Size of RAM - 128 MB

• 10/100/1000 Ethernet ports - 5

• PoE in - Yes, passive

• Supported input voltage - 12 - 57 V

• Power output - On ports 2-5, Output: 1A max per port; 2A max total (12-30v), 450mA max per port; 1,8A max total (31-57v)

• PCB temperature monitor - Yes

• Voltage monitor - Yes

• USB slot - Yes

• Dimensions - 114 x 137 x 29 mm

• License level - 4

• Operating System - RouterOS

• Max Power consumption - 54 W

• Max power consumption without attachments - 3 W

Package Contents

• 1 x hEX PoE Router RB960PGS

• 1 x Power Adapter

Warranty

• 1 Year Brand Warranty

Manufacturer Info

• Manufactured By: Mikrotikls SIA, Unijas iela 2, Riga, Latvia.

• Imported By: VT, New Delhi, INDIA.

• Country Of Origin: Vietnam
