Bungees 20KM HDMI KVM Extender over Fiber SC, BN-HFEX020KMK-SC, 1080p@60Hz, USB KVM Control, Single Mode Fiber, HDMI 1.4, HDCP 1.2

Description

The Bungees BN-HFEX020KMK-SC HDMI KVM Extender is engineered for ultra-long-distance signal transmission over single-mode optical fiber up to 20KM. Designed for high-performance environments, it delivers Full HD 1080p@60Hz video, along with USB keyboard and mouse control, ensuring seamless remote operation.

Using SC fiber interface, this extender eliminates electromagnetic interference and signal degradation, making it ideal for mission-critical applications such as industrial control systems, surveillance networks, broadcasting, and data centers.

With plug-and-play functionality, loop-out support, and compatibility with HDMI 1.4 and HDCP 1.2, this device provides a reliable, high-quality AV extension solution over extreme distances.

Key Features

• 20KM Ultra Long Distance - Transmit HDMI over single-mode fiber up to 20 kilometers

• KVM Remote Control - Operate systems remotely via USB keyboard & mouse

• SC Fiber Interface - Stable, interference-free optical transmission

• Full HD 1080p@60Hz - High-quality video output with smooth performance

• Loop Out Support - Local HDMI monitoring at transmitter side

• No Signal Loss / EMI Free - Ideal for industrial & professional use

Specifications

• Brand: Bungees

• Model: BN-HFEX020KMK-SC

• Product Type: HDMI KVM Extender over Fiber

• Transmission Distance: Up to 20KM

• Fiber Type: Single-mode (single-core)

• Fiber Interface: SC

• Video Resolution: 1920x1080 @ 60Hz

• HDMI Standard: HDMI 1.4

• HDCP Support: HDCP 1.2

• Video Bandwidth: 10.2 Gbps

• USB Version: USB 1.1 (Keyboard & Mouse)

• KVM Support: Yes

• Loop Out: Yes (TX side)

• Power Supply: DC 5V / 1A (2 adapters included)

• Power Consumption: 3W

• Operating Temperature: -15°C to +45°C

• Humidity Range: 5-90% RH (non-condensing)

• Dimensions: 95 x 75 x 28 mm (TX/RX)

Package Contents

• 1 x HDMI Transmitter (TX Unit)

• 1 x HDMI Receiver (RX Unit)

• 2 x Power Adapters

• 1 x USB Cable

Warranty

• 1 Year Brand Warranty

Manufacturer Info

• Imported By: BUNGEES NEW DELHI, INDIA

• Country Of Origin: China
