Bungees 20KM HDMI Fiber Extender SC, BN-HFEX020KM-SC, 1080p@60Hz HDMI over Single Mode Fiber, HDMI 1.4, HDCP 1.2, Ultra Long Distance

Description

The Bungees BN-HFEX020KM-SC HDMI Fiber Extender is designed to transmit Full HD HDMI signals up to 20 kilometers over single-mode optical fiber. Built for long-distance, high-performance applications, this extender ensures stable, interference-free signal transmission—perfect for environments where traditional copper cables cannot perform.

With support for Full HD 1080p@60Hz resolution, HDMI 1.4, and HDCP 1.2, it delivers crisp, reliable video quality for professional installations. The device also features loop-out functionality, allowing local display monitoring at the transmitter side.

Engineered with plug-and-play simplicity and a durable metal housing, this extender is ideal for broadcasting, surveillance systems, industrial setups, and large-scale AV deployments.

Key Features

• 20KM Transmission Distance - HDMI over single-mode fiber up to 20 kilometers

• Full HD 1080p@60Hz - High-quality video output

• SC Fiber Interface - Stable and secure optical connection

• Loop-Out Support - Local HDMI display at transmitter

• Zero Interference - Immune to EMI/RFI for stable performance

• Industrial-Grade Build - Reliable for continuous use

Specifications

• Brand: Bungees

• Model: BN-HFEX020KM-SC

• Product Type: HDMI Fiber Extender

• Transmission Distance: Up to 20KM

• Fiber Type: Single-mode (single-core)

• Fiber Interface: SC

• Video Resolution: 1920x1080 @ 60Hz

• HDMI Standard: HDMI 1.4

• HDCP Support: HDCP 1.2

• Video Bandwidth: 10.2 Gbps

• Loop Out: Yes (TX side)

• Power Supply: DC 5V / 1A (2 adapters included)

• Power Consumption: 3W

• Operating Temperature: -15°C to +45°C

• Humidity: 5-90% RH (non-condensing)

• Dimensions: 95 x 75 x 28 mm

Package Contents

• 1 x HDMI Transmitter (TX Unit)

• 1 x HDMI Receiver (RX Unit)

• 2 x Power Adapters

Warranty

• 1 Year Brand Warranty

Manufacturer Info

• Imported By: BUNGEES NEW DELHI, INDIA

• Country Of Origin: China
