TP-LINK TL-SG108E 8 Port Gigabit Smart Switch | Metal Casing, Fanless | 16 Gbps Switching Capacity, L2 Features

Name: TP-LINK TL-SG108E 8 Port Gigabit Smart Switch | Metal Casing, Fanless | 16 Gbps Switching Capacity, L2 Features
Brand: TP-Link
SKU: 141129
Price: 1995.0 INR
Availability: InStock
Rating: 5.0 (10 reviews)

8 10/100/1000Mbps RJ45 ports
Plug and play
Durable metal casing

Rs. 1,995.00

~~Rs. 3,999.00~~

Want it delivered by

Description
Reviews

Description

8 10/100/1000Mbps RJ45 ports
Plug and play, with no configuration required
Durable metal casing of superior quality and professional appearance
Intelligent management via a web user interface and downloadable utility
Green technology reduces power consumption

Specifications

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface	8 10/100/1000 Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity	Fanless
Power Supply	External Power Adapter(Output: 5 VDC/ 0.6 A)
Dimensions ( W x D x H )	6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
Max Power Consumption	3.68 W (220 V/ 50 Hz)
Max Heat Dissipation	12.55 BTU/h

PERFORMANCE
Switching Capacity	16 Gbps
Packet Forwarding Rate	11.9 Mpps
MAC Address Table	4 K
Packet Buffer Memory	1.5 Mb
Jumbo Frame	16 KB

SOFTWARE FEATURES
Quality of Service	Support Port-based/802.1p/DSCP priority Support 4 priority queues Rate Limit Storm Control
L2 Features	IGMP Snooping V1/V2/V3 Static Link Aggregation Port Mirroring Cable Diagnostics Loop Prevention
VLAN	Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN
Transmission Method	Store-And-Forward

OTHERS
Certification	FCC, CE, RoHS

System Requirements	Microsoft® Windows® for running Utility
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing

Package Contents

TL-SG108E
Power Adapter
Installation Guide
Rubber Feet

Warranty

3 Years Brand Warranty

Manufacturer Info

Manufactured By : Pacific Cyber Technology Private Limited , Daman and Diu , India.
Imported By :TP-LINK India Private Limited. Andheri East, Mumbai, India.
Country Of Origin : India
